Where Geometry is Complex, Seamless Insulation Wins: Aerogel Thermal Coating – 0.032 W/(m·K) Efficiency, A1 Fire Safety & Proven CUI Prevention

Where Geometry is Complex, Seamless Insulation Wins.
Pipes, valves, flanges, equipment housings, and building exteriors with irregular shapes have long been a nightmare for traditional insulation: joints create thermal bridges and leak heat, bulky layers add weight and labor costs, trapped moisture accelerates corrosion under insulation (CUI), and poor fire performance compromises safety. Teams spend days on multi-layer wrapping; operators pay high energy bills and face frequent maintenance.

Now a true game-changer exists: liquid aerogel thermal insulation coating. Brush or spray it like ordinary paint—it forms a seamless, monolithic nanoporous layer that thoroughly eliminates joints, prevents CUI, and delivers superior performance in ultra-thin applications.

Hebei Woqin's aerogel coating uses atmospheric pressure technology to disperse silica aerogel particles in a high-adhesion matrix, shattering limitations like peeling, high application energy, and flammability.

Technological Breakthroughs and Certifications
This coating delivers exceptional results without complex processes:

• Ultra-low thermal conductivity: 0.032 W/(m·K) at 25°C (GB/T 10295-2008)—just 0.5–2 mm thickness rivals much thicker conventional materials.
• Exceptional adhesion: 1.1 MPa bond strength (≥0.6 MPa required for exterior walls, JG/T 157-2009).
• Robust water resistance: No abnormality after 96h immersion (GB/T 1733-1993(2004)).
• A1 non-combustible fire rating (GB 8624-2012):

Third-party validation from CNAS-accredited labs (Report WT2024B01C01878, National Center for Quality Inspection and Testing of Building Materials). EU compliance via authorized representative TOCYA TRADING (79 rue de Patay, 75013 Paris, France; email: TOCYATRADING75013@outlook.com), valid September 9, 2025–September 9, 2026 (ProdSG §6).

Core Advantages in Real-World Performance
The nanoporous structure traps air, slashing conduction/convection/radiation. Seamless coverage on complex geometries eliminates thermal bridges and prevents CUI—no moisture ingress, no hidden corrosion. Anti-scalding surfaces protect personnel; thin application cuts weight, labor, and downtime.

Core Application Scenarios with Specific Impact Examples

1. Building Energy Efficiency
   Applied to exterior/interior walls, roofs, and HVAC in retrofits or new builds. Thin layers preserve space while cutting loads—aligning with green standards.
   Example: In a 1980s brick-concrete building retrofit, 2 mm coating replaced planned 60 mm external insulation, maintaining facade integrity while reducing winter heating energy consumption by 33% (similar to monitored cases in historic European retrofits).

Industrial Protection & CUI Mitigation
On high-temperature pipes/valves in refineries/chemical plants. Seamless application prevents CUI in corrosive/wet environments; anti-scalding enhances safety.

Example: In a coastal petrochemical facility's pipe corridor, 1.5 mm coating dropped surface temperature from 65°C to 39°C, eliminating scald risks and extending CUI protection cycles significantly (analogous to tested aerogel systems reducing burn hazards by 14–18°C and corrosion risks in marine/industrial settings).

1. New Energy & EV Battery Thermal Management
   Provides stable barriers for battery packs, maintaining performance across temperatures.
2. Infrastructure & Large-Scale Projects
   Supports low-carbon envelopes in industrial parks.

Typical Impact (from industry applications and testing):

• Pipe insulation: Surface temperatures drop significantly, minimizing heat loss and CUI risks.
• Building retrofits: Often achieve 30%+ heating/cooling energy savings, with seamless coverage on irregular surfaces.

Market Recognition and Prospects
The coating has passed energy-saving acceptance tests and is gaining adoption in construction, industrial, and new energy sectors. Global "dual carbon" initiatives drive demand for advanced liquid insulation. Hebei Woqin is scaling capacity to meet this growth.

Ready to Solve Your Challenges?
Request full reports (WT2024B01C01878+), samples, CAD details, or site trials. Let's discuss how this seamless coating fits your project.

Ruibin An
Hebei Woqin Trading Co., Ltd.
Phone/WhatsApp/WeChat: +86 139 3392 9092
Email:an@cn-aerogel.com
Website: insulatewool.com

Where geometry is complex, seamless aerogel coating delivers efficiency, safety, and savings—proven in real scenarios, without compromise.
